Product Specification
| Category | Specification |
|---|---|
| Device Name | Dashcam GPS |
| Model | T98 |
| Features | ADAS (Advanced Driver Assistance System), DMS (Driver Monitoring System) |
| Device Dimensions | 120mm (L) x 77mm (W) x 55mm (H) |
| Device Weight | 240g |
| Connectivity | 4G LTE |
| GNSS | GPS + BDS (with external G-mouse) |
| GPS Accuracy | ≤5m |
| Memory | DDR3 2GB |
| External Storage | Supports up to 512GB TF Card |
| Speakers | Built-in Speaker |
| Dual Camera | Front: 1080P with ADAS Cabin: 720P IR Night Vision with DMS |
| Camera Angle | Front: Wide 140°, Cabin: Wide-angle for complete in-cabin monitoring |
| Mic | Built-in Microphone |
| Operating Temperature | -20℃ to +70℃ |
| Operating System | Linux |
| G-Sensor | 3-axis acceleration sensor |
| Power Supply | DC: +9V to +36V |
| LED Indicators | Red (Power), Green (Internet & Video Recording) |
| I/O Ports | 2 Digital Inputs, 1 Digital Output for Relay, 1 RS232 |
Product Features
| Feature | Description |
|---|---|
| CPU | Powered by ARM Dual-Core 1.5GHz processor for smooth and efficient performance. |
| GNSS | Equipped with GPS + BDS for precise and reliable real-time positioning, ensuring accurate tracking. |
| G-Sensor | Integrated 3-axis acceleration sensor for collision detection, enhancing safety by automatically recording incidents. |
| Camera (Front) | 1080P ADAS front camera provides clear, high-definition video recording and advanced driver assistance. |
| Camera (Cabin) | 720P IR night vision DMS camera monitors driver behaviour, ensuring safety by detecting fatigue and distractions. |
| Video encoding | Supports H.264 and H.265 encoding for efficient video compression without compromising quality. |
| Mic | Built-in microphone enables two-way audio communication for real-time interaction. |
| Connectivity | 4G LTE and WiFi (2.4GHz) enabled for seamless data transmission and connectivity. |
| I/O Ports | Includes 2 digital inputs, 1 digital output for relay, and 1 RS232 port for flexible integrations. |
| Sim Card | Supports Micro SIM for stable cellular connectivity across multiple network bands. |
| Video Resolution | Capable of recording in 1080P at 100 fps, ensuring smooth and high-quality video output. |
| Power Supply | Operates on DC 9V – 36V, making it compatible with a wide range of vehicle types. |
| Operating Conditions | Functions reliably in harsh environments, with an operating temperature range of -20°C to +70°C and 20%-80% humidity. |
| Dimensions | Compact size of 120mm x 77mm x 55mm, weighing 240g, ideal for discreet vehicle installation. |
| ADAS & DMS | ADAS assists drivers by monitoring road conditions for potential hazards, while DMS tracks driver attentiveness using IR night vision to prevent accidents. |
