Specifications:
| Working frequency | RU864, IN865, EU868, US915, AU915, KR920, AS923 |
| CPU | Quad-core Cortex-A35 |
| System | Linux |
| RAM | 2GB |
| Security module | ATECC608B |
| ROM | eMMC 32GB (up to 128GB) |
| Network Interface | The network interface supports CAT-5 /CAT-5 E to transmit data and POE Power Supply (voltage range is 44 ~ 57V). It is WAN/ LAN variable |
| Indicator LEDs | 1 ) Power LED normally on when powered on 2 ) Network LED normally on when connected 3 ) LTE Card indicator |
| Ingress protection | IP67 |
| Communication | Wifi, BLE, LoRaWAN,LTE |
| GPS | GPS, GLONASS, Galileo and QZSS ( LTE Integrated) |
| Operating Temperature | -20 ℃~ 65 ℃ |
| LTE | Cat1 |
Features:
| Quad Core CPU，1.5GHz, 64-bit ARM、512MB DDR4、8GB eMMC； |
| Support 1Gb PoE switch power supply |
| Base on the LoRaWAN Concentrator Engine: Semtech SX1302 |
| Support WIFI 2.4G/5G IEEE 802.11b/g/n/ac, LTE Cat 1 4G |
| LoRaWAN Protocol：V1.0 Class A/Class B/Class C and V1.0.2 Class A/Class B/Class C； |
| Support BLE 5.2 |
| Support GPS, GLONASS, Galileo and QZSS |
| Support IP67 waterproof housing |
| Support OTA |
| Support MQTT & HTTP & HTTPS； |
| Support remote updates |
